Main Specification | |||||
Installation Site | Ground | Body Material | Aluminum-6005-T5 | ||
Tilt Angle | 0-45° | Bolt Material | SUS304 | ||
Max Wind Force | ≦60m/s | Base Material | Q235/Cement | ||
Snow Load | ≦1.4KN/㎡ | Surface Treatment | Anodized | ||
Ground Clearance | ≥300 mm | Warranty | 10 Years | ||
Module Directions | Portrait | Foundation | Concrete | ||
Landscape | Ground Screw | ||||
Design Standard | AS/NZ 1170,JIS C8955 2017, DIN 1055 ,IBC 2006 |
