GUÍA DE SELECCIÓN DEL CONTROLADOR DE ENERGÍA WD+

GUÍA DE SELECCIÓN DEL CONTROLADOR DE ENERGÍA WD+

Especificaciones/características clave

N º de Modelo.: Serie de PLC WD+ Hits: 0

WD+ PLC1.0 adopta Smartgen HGM6110N como controlador estándar; WD+ PLC2.0 adopta Deepsea HGM7310MKII como controlador estándar; WD+ PLC3.0 adopta Deepsea HGM8610MKII como controlador estándar;
Solicitar Compartir PDF
Etiquetas:

    Siguiente: GUÍA DE SELECCIÓN DE ATS (INTERRUPTOR DE TRANSFERENCIA AUTOMÁTICA)

    Información detallada

    CONTROLLER SELECTION TABLE
    CONTROLLER SPECIFICATION
    Model
    Function    		 WD+ PLC1.0 WD+ PLC2.0 WD+ PLC3.0
    HGM6110N HGM6120N DSE7310MKII DSE7320MKII DSE8610MKII DSE8620MKII
    Standard Option Standard Option Standard Option
    Manufacturer SMARTGEN DEEPSEA
    AMF × ● × ● Auto Start ●
    ECU ○ ○ ● ● ● ●
    Cummunication Port USB RS232/485/USB RS232/485/USB/ Ethernet
    Monitor Function Generator Set Voltage ● ● ● ● ● ●
    Generator Set Current ● ● ● ● ● ●
    Generator Set Frequency ● ● ● ● ● ●
    Generator Set Speed ● ● ● ● ● ●
    Generator Set Output Power ● ● ● ● ● ●
    Generator Set Power Factor ● ● ● ● ● ●
    Generator Set Run Hours ● ● ● ● ● ●
    Oil Pressure ● ● ● ● ● ●
    Water Temperature ● ● ● ● ● ●
    Battery Voltage ● ● ● ● ● ●
    Fuel Level ● ● ● ● ● ●
    Mains Voltage × ● × ● ● ●
    Mains Frequency × ● × ● ● ●
    Mains Current × ● × ● ● ●
    Synchronising × × × × ● ●
    Mains Parallel Operation × × × × ● ●
    Protection Low Oil Pressure ● ● ● ● ● ●
    Water Temperature High ● ● ● ● ● ●
    Over Speed ● ● ● ● ● ●
    Battery Charge Failure ● ● ● ● ● ●
    Reverse Power     × × × × ● ●
    Application × AMF+ATS × AMF+ATS Multiple Island or Single Parallel to Mains Single Parallel to Mains
    ● Standard ○Optional ×Impossible
